Phosphoserine Aminotransferase 1

Antibody: CPTC-PSAT1-1
Background

Catalog Number:

CPTC-PSAT1-1

RRID:

AB_10573019

Target Antigen:

Phosphoserine Aminotransferase 1

Isotype:

IgG2b

Species:

Mouse Monoclonal Antibody

Last Updated:

08/24/2021

Antigen Recognition(s):

Recombinant Full-length

SOP:

Purchase
Characterization Data [Compare Characterization Data]
  IHC HPA
Download This PDF contains the evaluation results provided by the Human Protein Atlas (www.proteinatlas.org) (123.0 KB)

CPTC-PSAT1-1 Evaluation by the Human Protein Atlas

Result: Negative

This PDF contains the evaluation results provided by the Human Protein Atlas (www.proteinatlas.org)


Characterization SOP Files

  IHC NCI60

CPTC-PSAT1-1 IHC NCI60

Result: Negative

This antibody is not suitable for use in an Immunohistochemistry format as described in SOP M-106.


Characterization SOP Files

  IHC Tissue

CPTC-PSAT1-1 IHC Tissue

Result: Negative

This antibody is not suitable for use in an Immunohistochemistry format as described in SOP M-106.


Characterization SOP Files

  Indirect ELISA
Click to enlarge image Indirect ELISA (ie, binding of Antibody to Antigen coated plate) Click image to enlarge

CPTC-PSAT1-1 Indirect ELISA

Result: High Binding

Indirect ELISA (ie, binding of Antibody to Antigen coated plate)


Characterization SOP Files

  NCI 60 Protein Array

CPTC-PSAT1-1 NCI 60 Protein Array

Result: Negative

This antibody is not suitable for use in a Reverse Phase Protein Array format as described in SOP M-105.


Characterization SOP Files

  Western Blot - Recombinant Protein or Peptide
Click to enlarge image Western Blot using CPTC-PSAT1-1 as primary Ab against PSAT1 (Ag 10106) (lane 2). Also included are molecular wt. standards (lane 1) and mouse IgG control (lane 3). Click image to enlarge

CPTC-PSAT1-1 Western Blot

Result: Positive

Western Blot using CPTC-PSAT1-1 as primary Ab against PSAT1 (Ag 10106) (lane 2). Also included are molecular wt. standards (lane 1) and mouse IgG control (lane 3).


Characterization SOP Files

[top]

Antibody: CPTC-PSAT1-2
Background

Catalog Number:

CPTC-PSAT1-2

RRID:

AB_10586639

Target Antigen:

Phosphoserine Aminotransferase 1

Isotype:

IgG1

Species:

Mouse Monoclonal Antibody

Last Updated:

08/03/2026

Antigen Recognition(s):

Recombinant Full-length, Endogenous

SOP:

Purchase
External Links
Characterization Data [Compare Characterization Data]
  CyTOF
Click to enlarge image Imaging mass cytometry on ovarian cancer tissue core using CPTC-PSAT1-2 metal-labeled antibody. Data shows an overlay of the target protein signal (red) and DNA (blue). Dilution: 1:100 of 0.5mg/mL stock. Signal was also obtained in other normal tissues (testis, liver, endometrium, appendix, pancreas, bone marrow, breast, and kidney) and cancer tissues (breast, colon, prostate, lung, and ovarian). Click image to enlarge

CPTC-PSAT1-2 Immuno-Mass Cytometry

Result: Positive

Imaging mass cytometry on ovarian cancer tissue core using CPTC-PSAT1-2 metal-labeled antibody. Data shows an overlay of the target protein signal (red) and DNA (blue). Dilution: 1:100 of 0.5mg/mL stock. Signal was also obtained in other normal tissues (testis, liver, endometrium, appendix, pancreas, bone marrow, breast, and kidney) and cancer tissues (breast, colon, prostate, lung, and ovarian).


Characterization SOP Files

  IHC HPA
Download This PDF contains the evaluation results provided by the Human Protein Atlas (www.proteinatlas.org) (176.5 KB)

CPTC-PSAT1-2 Evaluation by the Human Protein Atlas

Result: Positive

This PDF contains the evaluation results provided by the Human Protein Atlas (www.proteinatlas.org)


Characterization SOP Files

  IHC NCI60
Click to enlarge image Immunohistochemistry of CPTC-PSAT1-2 for NCI60 Cell Line Array. Data scored as: 0=NEGATIVE 1=WEAK (red) 2=MODERATE (blue) 3=STRONG (green) Titer: 1:50 Click image to enlarge

CPTC-PSAT1-2 IHC NCI60

Result: Positive

Immunohistochemistry of CPTC-PSAT1-2 for NCI60 Cell Line Array. Data scored as:
0=NEGATIVE
1=WEAK (red)
2=MODERATE (blue)
3=STRONG (green)
Titer: 1:50


Characterization SOP Files

  IHC Tissue
Click to enlarge image Tissue Micro-Array(TMA) core of colon cancer showing cytoplasmic staining using Antibody CPTC-PSAT1-2. Titer: 1:50 Click image to enlarge

CPTC-PSAT1-2 IHC Tissue

Result: Positive

Tissue Micro-Array(TMA) core of colon cancer showing cytoplasmic staining using Antibody CPTC-PSAT1-2. Titer: 1:50


Characterization SOP Files

  Immunofluorescence - HPA
Click to enlarge image Results provided by the Human Protein Atlas (www.proteinatlas.org). The subcellular location is supported by literature. Immunofluorescent staining of human cell line A-431 shows localization to cytosol. Human assay: A-431 fixed with PFA, dilution: 1:20 Human assay: U-2 OS fixed with PFA, dilution: 1:20 Human assay: U-251 MG fixed with PFA, dilution: 1:20 Click image to enlarge

CPTC-PSAT1-2 Evaluation by the Human Protein Atlas

Result: Positive

Results provided by the Human Protein Atlas (www.proteinatlas.org). The subcellular location is supported by literature. Immunofluorescent staining of human cell line A-431 shows localization to cytosol.

Human assay: A-431 fixed with PFA, dilution: 1:20
Human assay: U-2 OS fixed with PFA, dilution: 1:20
Human assay: U-251 MG fixed with PFA, dilution: 1:20


Characterization SOP Files

  Indirect ELISA
Click to enlarge image Indirect ELISA (ie, binding of Antibody to Antigen coated plate) Click image to enlarge

CPTC-PSAT1-2 Indirect ELISA

Result: High Binding

Indirect ELISA (ie, binding of Antibody to Antigen coated plate)


Characterization SOP Files

  NCI 60 Protein Array
Click to enlarge image Protein Array in which CPTC-PSAT1-2 is screened against the NCI60 cell line panel for expression. Data is normalized to a mean signal of 1.0 and standard deviation of 0.5. Color conveys over-expression level (green), basal level (blue), under-expression level (red). Click image to enlarge

CPTC-PSAT1-2 Protein Array

Result: Positive

Protein Array in which CPTC-PSAT1-2 is screened against the NCI60 cell line panel for expression. Data is normalized to a mean signal of 1.0 and standard deviation of 0.5. Color conveys over-expression level (green), basal level (blue), under-expression level (red).


Characterization SOP Files

  Western Blot - HPA - tissue or cell lysate
Click to enlarge image Results provided by the Human Protein Atlas (www.proteinatlas.org). Single band corresponding to the predicted size in kDa (+/-20%). Analysis performed using a standard panel of samples. Antibody dilution: 1:250 Click image to enlarge

CPTC-PSAT1-2 Evaluation by the Human Protein Atlas

Result: Positive

Results provided by the Human Protein Atlas (www.proteinatlas.org). Single band corresponding to the predicted size in kDa (+/-20%). Analysis performed using a standard panel of samples. Antibody dilution: 1:250


Characterization SOP Files

  Western Blot - Recombinant Protein or Peptide
Click to enlarge image Western Blot using CPTC-PSAT1-2 as primary Ab against PSAT1 (Ag 10106) (lane 2). Also included are molecular wt. standards (lane 1) and mouse IgG control (lane 3). Click image to enlarge

CPTC-PSAT1-2 Western Blot

Result: Positive

Western Blot using CPTC-PSAT1-2 as primary Ab against PSAT1 (Ag 10106) (lane 2). Also included are molecular wt. standards (lane 1) and mouse IgG control (lane 3).


Characterization SOP Files

[top]

Antibody: CPTC-PSAT1-3
Background

Catalog Number:

CPTC-PSAT1-3

RRID:

AB_10567265

Target Antigen:

Phosphoserine Aminotransferase 1

Isotype:

IgG1

Species:

Mouse Monoclonal Antibody

Last Updated:

08/24/2021

Antigen Recognition(s):

Recombinant Full-length, Endogenous

SOP:

Purchase
Characterization Data [Compare Characterization Data]
  IHC HPA
Download This PDF contains the evaluation results provided by the Human Protein Atlas (www.proteinatlas.org) (117.3 KB)

CPTC-PSAT1-3 Evaluation by the Human Protein Atlas

Result: Positive

This PDF contains the evaluation results provided by the Human Protein Atlas (www.proteinatlas.org)


Characterization SOP Files

  IHC NCI60
Click to enlarge image Immunohistochemistry of CPTC-PSAT1-3 for NCI60 Cell Line Array. Data scored as: 0=NEGATIVE 1=WEAK (red) 2=MODERATE (blue) 3=STRONG (green) Titer: 1:50 Click image to enlarge

CPTC-PSAT1-3 IHC NCI60

Result: Positive


Immunohistochemistry of CPTC-PSAT1-3 for NCI60 Cell Line Array. Data scored as:
0=NEGATIVE
1=WEAK (red)
2=MODERATE (blue)
3=STRONG (green)
Titer: 1:50


Characterization SOP Files

  IHC Tissue
Click to enlarge image Tissue Micro-Array(TMA) core of colon cancer showing cytoplasmic staining using Antibody CPTC-PSAT1-3. Titer: 1:50 Click image to enlarge

CPTC-PSAT1-3 IHC Tissue

Result: Positive

Tissue Micro-Array(TMA) core of colon cancer showing cytoplasmic staining using Antibody CPTC-PSAT1-3. Titer: 1:50


Characterization SOP Files

  Indirect ELISA
Click to enlarge image Indirect ELISA (ie, binding of Antibody to Antigen coated plate) Click image to enlarge

CPTC-PSAT1-3 Indirect ELISA

Result: High Binding

Indirect ELISA (ie, binding of Antibody to Antigen coated plate)


Characterization SOP Files

  NCI 60 Protein Array
Click to enlarge image Protein Array in which CPTC-PSAT1-3 is screened against the NCI60 cell line panel for expression. Data is normalized to a mean signal of 1.0 and standard deviation of 0.5. Color conveys over-expression level (green), basal level (blue), under-expression level (red). Click image to enlarge

CPTC-PSAT1-3 Protein Array

Result: Positive

Protein Array in which CPTC-PSAT1-3 is screened against the NCI60 cell line panel for expression. Data is normalized to a mean signal of 1.0 and standard deviation of 0.5. Color conveys over-expression level (green), basal level (blue), under-expression level (red).


Characterization SOP Files

  Western Blot - Recombinant Protein or Peptide
Click to enlarge image Western Blot using CPTC-PSAT1-3 as primary Ab against PSAT1 (Ag 10106) (lane 2). Also included are molecular wt. standards (lane 1) and mouse IgG control (lane 3). Click image to enlarge

CPTC-PSAT1-3 Western Blot

Result: Positive

Western Blot using CPTC-PSAT1-3 as primary Ab against PSAT1 (Ag 10106) (lane 2). Also included are molecular wt. standards (lane 1) and mouse IgG control (lane 3).


Characterization SOP Files

[top]

Antibody: CPTC-PSAT1-4
Background

Catalog Number:

CPTC-PSAT1-4

RRID:

AB_10568664

Target Antigen:

Phosphoserine Aminotransferase 1

Isotype:

IgG1

Species:

Mouse Monoclonal Antibody

Last Updated:

08/24/2021

Antigen Recognition(s):

Recombinant Full-length

SOP:

Purchase
Characterization Data [Compare Characterization Data]
  IHC HPA
Download This PDF contains the evaluation results provided by the Human Protein Atlas (www.proteinatlas.org) (121.1 KB)

CPTC-PSAT1-4 Evaluation by the Human Protein Atlas

Result: Negative

This PDF contains the evaluation results provided by the Human Protein Atlas (www.proteinatlas.org)


Characterization SOP Files

  IHC NCI60

CPTC-PSAT1-4 IHC NCI60

Result: Negative

This antibody is not suitable for use in an Immunohistochemistry format as described in SOP M-106.


Characterization SOP Files

  IHC Tissue

CPTC-PSAT1-4 IHC Tissue

Result: Negative

This antibody is not suitable for use in an Immunohistochemistry format as described in SOP M-106.


Characterization SOP Files

  Indirect ELISA
Click to enlarge image Indirect ELISA (ie, binding of Antibody to Antigen coated plate) Click image to enlarge

CPTC-PSAT1-4 Indirect ELISA

Result: High Binding

Indirect ELISA (ie, binding of Antibody to Antigen coated plate)


Characterization SOP Files

  NCI 60 Protein Array

CPTC-PSAT1-4 NCI 60 Protein Array

Result: Negative

This antibody is not suitable for use in a Reverse Phase Protein Array format as described in SOP M-105.


Characterization SOP Files

[top]

Antigen: Phosphoserine Aminotransferase 1
Background

NCI Identification Number:

10106

Antigen Name:

Phosphoserine Aminotransferase 1

CPTC Name:

CPTC-PSAT1

Aliases:

PSAT; PSA; OTTHUMP00000021524; OTTHUMP00000021525; MGC1460; EPIP; EC 2.6.1.52

Function:

The protein encoded by this gene is likely a phosphoserine aminotransferase, based on similarity to proteins in mouse, rabbit, and Drosophila. Alternative splicing of this gene results in two transcript variants encoding different isoforms.

Catalyzes the reversible conversion of 3-phosphohydroxypyruvate to phosphoserine and of 3-hydroxy-2-oxo-4-phosphonooxybutanoate to phosphohydroxythreonine.

Chromosomal Localization:

9q21.2

Expression System:

E. Coli

Accession Number:

BC004863

UniProt Accession Number:

Q9Y617

DNA Source:

HIP : HsCD00003584

Immunogen:

Recombinant Full Length Protein

Vector Name:

pMCSG7

Extinction Coefficient:

36058

Buffers:

50mM NH4HC03

Expressed Sequence:

SNAMDAPRQVVNFGPGPAKLPHSVLLEIQKELLDYKGVGISVLEMSHRSS
DFAKIINNTENLVRELLAVPDNYKVIFLQGGGCGQFSAVPLNLIGLKAGR
CADYVVTGAWSAKAAEEAKKFGTINIVHPKLGSYTKIPDPSTWNLNPDAS
YVYYCANETVHGVEFDFIPDVKGAVLVCDMSSNFLSKPVDVSKFGVIFAG
AQKNVGSAGVTVVIVRDDLLGFALRECPSVLEYKVQAGNSSLYNTPPCFS
IYVMGLVLEWIKNNGGAAAMEKLSSIKSQTIYEIIDNSQGFYVCPVEPQN
RSKMNIPFRIGNAKGDDALEKRFLDKALELNMLSLKGHRSVGGIRASLYN
AVTIEDVQKLAAFMKKFLEMHQL

Native Sequence:

MDAPRQVVNFGPGPAKLPHSVLLEIQKELLDYKGVGISVLEMSHRSSDFA
KIINNTENLVRELLAVPDNYKVIFLQGGGCGQFSAVPLNLIGLKAGRCAD
YVVTGAWSAKAAEEAKKFGTINIVHPKLGSYTKIPDPSTWNLNPDASYVY
YCANETVHGVEFDFIPDVKGAVLVCDMSSNFLSKPVDVSKFGVIFAGAQK
NVGSAGVTVVIVRDDLLGFALRECPSVLEYKVQAGNSSLYNTPPCFSIYV
MGLVLEWIKNNGGAAAMEKLSSIKSQTIYEIIDNSQGFYVCPVEPQNRSK
MNIPFRIGNAKGDDALEKRFLDKALELNMLSLKGHRSVGGIRASLYNAVT
IEDVQKLAAFMKKFLEMHQL

Calculated Isoelectric Point:

7.54

Molecular Weight:

40695

Last Updated:

08/03/2009

Links

Characterization Data

Gel

Click to enlarge image PAGE of PSAT1 (AG 10106) with molecular weight standards in lane 1
Click image to enlarge

CPTC-PSAT1 PAGE

PAGE of PSAT1 (AG 10106) with molecular weight standards in lane 1

No SOPs available.
